Item NO.:
GZCHPayment:
T/TProduct Origin:
Guangdong, ChinaColor:
CustomizedShipping Port:
GuangzhouMin order:
5Lead Time:
30 working days after confirm the P.O &DProduct Paramenters
Technical Parameters | Description | ||
Product name | Prefab house | ||
Country of Origin | Guandong, China | ||
Color | customized | ||
Design | Flexible design | ||
Materials | Steel and sandwich panel | ||
Transportation | By sea | ||
Brand | GUIZU | ||
uses | residential and commercial | ||
Frame | Welded/ Hot rolled H beam | ||
Type | packing container, shipping container reconstruction or customized | ||
Interior decoration | customized | ||
Certification | SGS | ||
Wall and Roof | EPS or glass wool panel | ||
Window | PVC or Aluminum Alloy | ||
Steel standard | Q235 | ||
Wind load | <35m/s | ||
Earthquake resistance | 7 fission resistant |
Specification of Raw Materials
item | EPS | Glass Wool | TPS Board | Rock Wool |
waterproof | ★★★★★ | ★★★ | ★★★★★ | ★★★ |
fireproof | ★★ | ★★★★★ | ★★★★★ | ★★★★★ |
Heat Insulation | ★★★ | ★★★★ | ★★★★ | ★★★★ |
Sound Insulation | ★★★★ | ★★★★ | ★★★★★ | ★★★★ |
Price Comparison | ★★ | ★★★ | ★★ | ★★★★ |
Density Range | 10-14kg/m3 | 100-120kg/m3 | 40-200kg/m3 | 100-250kg/m3 |
Accessories Name | Description |
Ground Beam |
14#/16# H-beam, 12# channel steel; 100*100*3.0 /150*75*3.0 / 120*60*3.0galvanized steel tube; 120*120*3.0 / 150*150*3.0 bending parts |
Pillar/Column |
100*100*3.0 /150*75*3.0 / 120*60*3.0galvanized steel tube; 120*120*3.0 / 150*150*3.0 bending parts |
Floor beam |
100*100*3.0 / 150*75*3.0 / 120*60*3.0 / 60*60*2.0 galvanized steel tube; 60*60*3.0 / 120*120*3.0 / 150*150*3.0 bending parts |
Floor Purlin |
8# channel steel; 80*80*2.0 / 50*100*2.0 / 40*80*2.0 galvanized steel tube |
Stairs | 150*30 C-type steel |
Walkway Board | anticorrisive woods |
External Wall |
0.8mm/1.5mm/2.0mm Corrugated galvanized steel board; 0.46mm pre-painted galvanized steel board |
Internal Wall | 0.46mm / 0.36mm / 0.26mm pre-painted galvanized steel board |
Roof Panel |
0.8mm/1.5mm/2.0mm Corrugated galvanized steel board; 0.46mm pre-painted galvanized steel board |
Edge | PVC capping seal, bamboo and woods fiber capping seal |
Floor | Glass magnesium board, PVC composition tile, ceramic tiles |
Window | Sliding window, casement window, hanging window, double-glazed glass window(thickness can be customized) |
Door |
Security door, plastic steel door, steel door, stainless steel door |
